Single Shaft Horizontal Ribbon Mixer

Name: Single Shaft Horizontal Ribbon Mixer
Brand: BEISU
Price: 6 USD

Buy cheap Single Shaft Horizontal Ribbon Mixer product

Condition : New

Material : Stainless Steel

Output (kg/h) : 1900 - 2000kg/h

Capacity (kg) : 2000

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Marketing Type : New Product 2020

Warranty of core components : 1 Year

Core Components : Pump, Pump, Pump, Pump, Pump, Pump, Pump

Application : Plastic Mixer

Automatic Grade : Automatic

Voltage : Customzied

Dimension(L*W*H) : Customized

Warranty : 1 Year

After-sales Service Provided : Video technical support, Video technical support, Video technical support, Video technical support, Video technical support

Weight (KG) : 1500 KG

Power (kW) : 18.5

Applicable Industries : Food & Beverage Factory, Food & Beverage Factory

After Warranty Service : Field maintenance and repair service, Field maintenance and repair service, Field maintenance and repair service, Field maintenance and repair service

Local Service Location : Algeria, Algeria, Algeria

Showroom Location : none, none, none, none, none, none, none, none, none, none, none, none, none, none, none, none

Raw Material : PVC/PE/PP Powder, Granules or Liquid

Mixing speed : 20-40 RPM can be customized

Material of mixing blade : S.S304

Method of mixing blade : Double

Hot mixing motor power : 18.5Kw

Mixing bearing brand : NSK, SKF or WANFANDIAN

Cold mixing drive method : Belt reducer

Temperature brand : OMRON,JAPAN

Contactor brand : SCHNEIDER or Internationally renowned brand

Port : SHANGHAI or NINGBO PORT

Place of Origin : CN;JIA

Brand Name : BEISU

Certification : CE ISO

Supply Ability : 250 Set/Sets per Year for PVC mixer

Packaging Details : Plastic film packing or wood package as customer requirements

MOQ : 1 - 2 Sets

Price : $6,300.00

Contact Now

Application range of high-efficiency horizontal ribbon blender mixer: High-efficiency horizontal ribbon mixer is used in pesticides, veterinary drugs, food, chemicals, biology, aquaculture, ceramics, refractory materials, plastics, compound fertilizers, etc. solid-solid (ie powder and powder) solid-slurry ( That is the mixing of powder and mucilage), it is especially suitable for mixing viscous materials.

The structure of the high-efficiency horizontal ribbon mixer: A1: The mixing blade of the horizontal spiral belt mixer and the contact part of the material are all made of stainless steel, which has good corrosion resistance, keeps the quality and cleanness of the material, and does not cause discoloration; A2: The mixing capacity of the horizontal ribbon mixer is available in multiple models with a capacity of 50-20000L, and long-term spot for customers to choose; A3: The reducer of the horizontal spiral belt mixer is the main transmission structure of the mixer. It is located on the right side of the machine. When working, the motor installed in the base machine drives the worm and worm gear through the V-belt, and drives it at a speed of 1:40. Blender. The worm gear shaft is hollow and is equipped with a fixed key, which allows the mixing paddle to be assembled and disassembled freely. There are two ring screws on the top of the reducer for assembly, disassembly and installation; A4: The tank of the horizontal ribbon mixer is U-shaped, made of stainless steel, with mixing blades inside, lying horizontally on the reducer and dumping reducer of the horizontal mixer. The horizontal mixer is an integral structure. The motor is installed on the movable plates on both sides of the base. The upper and lower parts of the motor can be adjusted by the screw, so that the triangle belt can get a certain degree of tension and maintain the transmission force. A5: The transmission mechanism of the horizontal spiral belt mixer adopts worm gear and worm to directly drive, there is no excessive loud noise when in use, and there is enough oil storage to get good lubrication.

Model	Size (mm)	Weight (KG)	Power (Kw)	Capacity	Effective volume(m³)
100	13006501200	150	2.2	200-300kg/h	0.3
250	21008001400	280	4	400-600kg/h	0.5
500	32009501800	638	7.5	1500-2000kg/h	1
1000	380012002100	836	11	3000-4000kg/h	3
1000B	380012001800	810	11	3000-4000kg/h	2
2000	420014502400	1658	18.5	6000-10000kg/h	4

Features of high-efficiency horizontal ribbon mixer:

A1: Easy to install and movable. If multiple mixers use the same material, only one feeder can feed multiple mixers at the same time, eliminating the trouble of manual processing and making the feeding work safer and more secure. Save time and effort. A2: The design is reasonable and the operation and maintenance are convenient. Compared with the vacuum feeder, it can avoid the trouble of cleaning the filter frequently. A3: It adopts famous factory reducer or gear box to reduce speed, which is safe, stable and reliable. Ensure that the system operation and conveying capacity meet the greater requirements of customers. In addition, Beisu Machinery has dust removal feeder, vacuum suction machine, conveyor belt, and other supporting equipment, minus the feeding platform, reduces labor intensity, saves time and labor. It is safe, fast and convenient; there is a storage barrel at the back end, automatic weighing and packing system and other automatic equipment.
